ANGULUS FLUVIA FLAME
Five individually controllable flames create a distinctive fan-shaped flame effect. Each flame can be triggered independently, while the flame height can be adjusted from 6 to 20 meters for all five flames together.
Touring-ready construction with plug-and-play setup. All components are accessible for quick backstage servicing with minimal tools. Integrated truss mounting rails enable fast and flexible installation.
Integrated self-priming pump technology eliminates the need for an external pump station. Fuel can be drawn over distances of up to 40 meters and elevations of up to 10 meters. For longer supply distances, the optional Liquid Booster is available.
Fully integrated into the proTEC Safety Architecture, providing structured emergency-stop logic and reliable system integration. Compatible with DMX, ArtNet, and sACN.
Compatible with alcohols, Isopar, diesel, and gasoline. Fuel can be supplied from canisters, drums, IBCs, or other suitable fuel containers.
Adjustable Flame Height from 6 to 20 m
​
Compact, Touring-Ready Design
proTEC Safety Architecture
Self-Priming Pump System
No external pump station
Five Individually Controllable Flames
Distinctive Fan-Shaped Flame Effect
Four reinforced lifting eyes enable secure crane handling and help ensure balanced lifting and stability during installation, supporting the safe securing of the device.
TECHNICAL SPECIFICATIONS
Control Protocols
DMX-512 | RDM | ArtNET | sACN | proTEC safety potocol
DMX Channels
8
Control Modes
1 | Free
Power Input
Neutrik powerCON TRUE1 In/Out
Fluid Connection
TBF CBC 005-WR013 (Clean-Break Coupling)
Signal Connection
Neutrik XLR 5-Pin In/Out | Neutrik XLR 3-Pin In/Out | Neutrik etherCON port A & B
Housing Material
The enclosure features a stainless steel construction with a black powder-coated finish using a special flame-retardant coating, complemented by aluminum components.
Protection Rating
IP41 | with rain cover IP 44
Construction Features
Multicolor touch display | Battery-powered display | Webserver
Power Input
100 – 240 VAC / 50 – 60 Hz
max. Power (230V)
2000 W
Mounting
Truss 3x Base Plate – Vertical Flex Line 4x M10
Orientation
any | vertical hanging | horizontal sideway
Sunction Height
10 m /32,8 ft | Above 10 m / 32,8 ft Liquid Booster needed
Flame Height
6- 20 m / 19,7- 65,6 ft
Authorized Liquids
Alcohols | Isopar | Diesel | Gasoline
Single Fixture
Carton
Tourpack
Single Case
Height
572 mm / 22.52 in
Width
743 mm/ 29.25 in
Depth
1010 mm / 39.76 in
Weight (netto)
118 kg / 260.15 lbs
